COMPASS - Spatial Synthetic Population Generator

Work in Progress - Not Ready for Production Use

This is a research/experimental project for generating spatial synthetic populations. The code is under active development and not yet intended for public release or real-world use. But is getting there!

Overview

COMPASS is a Go-based tool for generating synthetic populations by combining census data with survey microdata using simulated annealing optimization. It creates spatially detailed synthetic populations that match statistical constraints from census data while preserving individual characteristics from survey microdata.

How It Works

The tool uses simulated annealing, a probabilistic optimization algorithm, to select a subset of microdata records for each geographic area:

1. Input Loading: Reads constraint data (census totals), microdata (survey records), and geographical groupings
2. Initialization: Creates a random population by sampling microdata records for each area
3. Optimization Loop:
   • Proposes changes by swapping one microdata record with another
   • Accepts or rejects changes based on fitness improvement and current temperature
   • Gradually cools the temperature to converge on a good solution
   • Reheats if progress stalls to escape local optima
4. Output Generation: Writes final population mappings and validation data

Key Features

• Parallel Processing: Utilizes all CPU cores for fast population generation
• Multiple Distance Metrics: KL Divergence, Chi-Squared, Euclidean, Cosine, MSE, and more
• Deterministic Mode: Reproducible results with fixed random seeds
• Adaptive Thresholds: Automatically adjusts convergence criteria based on the chosen metric
• Multi-Language API: Call from Python, R, or directly via command line
• UK-Focused Design: Optimized for UK census geography and Understanding Society data

Installation

Pre-compiled Binaries

Pre-compiled executables are available for:

Prerequisites (Building from Source)

• Go 1.18+ (required for building)
• Python 3.6+ (optional, for Python interface)
• R 4.0+ with jsonlite package (optional, for R interface)

Quick Start (Using Pre-compiled Binary)

# Download the Linux binary
chmod +x compass_linux_amd64

# Test it works
./compass_linux_amd64 -f config.json

# Or pipe JSON directly
echo '{"constraints":"data.csv","microdata":"micro.csv"}' | ./compass_linux_amd64

Building from Source

# Clone the repository
git clone <repository-url>
cd compass

# Build the binary
go build -o compass .

# Make it executable (Linux/macOS)
chmod +x compass

# Test the build
./compass -f config.json

Usage

Command Line Interface

The tool accepts JSON configuration either from a file or via stdin:

# Method 1: JSON file input
./compass_linux_amd64 -f config.json

# Method 2: Pipe JSON to stdin
echo '{"constraints":"data.csv","microdata":"micro.csv"}' | ./compass_linux_amd64

Python Interface

#!/usr/bin/env python3
import json
import subprocess
import sys
from pathlib import Path

def run_compass(config_dict, binary_path="./compass_linux_amd64"):
    """
    Run COMPASS from Python with a configuration dictionary.

    Args:
        config_dict: Dictionary containing COMPASS configuration parameters
        binary_path: Path to compiled COMPASS binary (default: "./compass_linux_amd64")

    Returns:
        Dictionary with results including status, message, and log
    """
    # Convert to compact JSON
    json_input = json.dumps(config_dict, separators=(',', ':'), ensure_ascii=False)

    try:
        # Execute COMPASS
        result = subprocess.run(
            [binary_path],
            input=json_input,
            capture_output=True,
            text=True,
            check=False
        )

        # Parse JSON response
        if result.stdout:
            response = json.loads(result.stdout)
        else:
            response = {"status": "error", "message": "No output from COMPASS"}

        # Add execution details
        response["return_code"] = result.returncode
        if result.stderr:
            response["stderr"] = result.stderr.splitlines()

        return response

    except json.JSONDecodeError as e:
        return {
            "status": "error",
            "message": f"Failed to parse COMPASS output: {str(e)}",
            "raw_output": result.stdout if 'result' in locals() else None
        }
    except Exception as e:
        return {
            "status": "error",
            "message": f"Failed to execute COMPASS: {str(e)}"
        }

# Example usage
if __name__ == "__main__":
    config = {
        "constraints" : "data/BlockLand/artifical_cencus.csv",
        "microdata"   : "data/BlockLand/artifical_hh_survay.csv",
        "groups"      : "data/BlockLand/artificial_groups.csv",
        "output"      : "results/artificial_synthetic_population.csv",
        "validate"    : "results/artificial_synthPopSurvey.csv",
        "initialTemp": 1000.0,
        "minTemp": 0.001,
        "coolingRate": 0.997,
        "reheatFactor": 0.3,
        "fitnessThreshold": 0.01,
        "minImprovement": 0.001,
        "maxIterations": 500000,
        "windowSize": 5000,
        "change": 100000,
        "distance": "NORM_EUCLIDEAN",
        "useRandomSeed": "no",
        "randomSeed": 42
    }

    result = run_compass(config)
    print("Status:", result.get("status"))
    print("Message:", result.get("message"))

    if "log" in result:
        print("\nExecution Log:")
        for line in result["log"]:
            print(f"  {line}")

R Interface

# R script: run_compass.R
library(jsonlite)

run_compass <- function(config_list, binary_path = "./compass_linux_amd64") {
  #' Run COMPASS from R with a configuration list
  #'
  #' @param config_list List containing COMPASS configuration parameters
  #' @param binary_path Path to compiled COMPASS binary (default: "./compass_linux_amd64")
  #' @return List with results including status, message, and execution details

  # Convert to compact JSON
  json_input <- toJSON(config_list, auto_unbox = TRUE, pretty = FALSE)

  # Execute COMPASS
  result <- system2(
    binary_path,
    input = json_input,
    stdout = TRUE,
    stderr = TRUE
  )

  # Parse output
  output <- paste(result$stdout, collapse = "\n")

  if (nchar(output) > 0) {
    tryCatch({
      response <- fromJSON(output)
    }, error = function(e) {
      response <- list(
        status = "error",
        message = paste("Failed to parse JSON:", e$message),
        raw_output = output
      )
    })
  } else {
    response <- list(status = "error", message = "No output from COMPASS")
  }

  # Add execution details
  response$return_code <- attr(result, "status")
  if (!is.null(result$stderr) && length(result$stderr) > 0) {
    response$stderr <- result$stderr
  }

  return(response)
}

# Example usage
config <- list(
  constraints = "data/BlockLand/artifical_cencus.csv",
  microdata   = "data/BlockLand/artifical_hh_survay.csv",
  groups      = "data/BlockLand/artificial_groups.csv",
  output      = "results/artificial_synthetic_population.csv",
  validate    = "results/artificial_synthPopSurvey.csv",
  initialTemp = 1000.0,
  minTemp = 0.001,
  coolingRate = 0.997,
  reheatFactor = 0.3,
  fitnessThreshold = 0.01,
  minImprovement = 0.001,
  maxIterations = 500000,
  windowSize = 5000,
  change = 100000,
  distance = "NORM_EUCLIDEAN",
  useRandomSeed = "no",
  randomSeed = 42
)

result <- run_compass(config)
cat("Status:", result$status, "\n")
cat("Message:", result$message, "\n")

if (!is.null(result$log)) {
  cat("\nExecution Log:\n")
  for (line in result$log) {
    cat(" ", line, "\n")
  }
}

Configuration

Required Parameters

Optional Parameters

Input File Formats

Constraints CSV

id,total,var1,var2,var3,...
A001,100,25,40,35,...
A002,150,60,50,40,...

Microdata CSV

id,var1,var2,var3,...
P001,1,0,1,...
P002,0,1,1,...

Groups CSV

variable,group
var1,1
var2,2
var3,1

Distance Metrics

The distance parameter determines how the algorithm measures the difference between the synthetic population and the constraints.

Metric Behavior

Simulated Annealing Parameter Guide

Temperature Parameters

Convergence Control

Stagnation Handling

Parameter Interplay Examples

Quick Convergence Setup (Fast results, "good enough" acceptable):

{
  "initialTemp": 500.0,
  "coolingRate": 0.99,
  "fitnessThreshold": 0.05,
  "maxIterations": 100000,
  "reheatFactor": 0.5
}

Thorough Search Setup (Best possible solution, more time):

{
  "initialTemp": 2000.0,
  "coolingRate": 0.998,
  "fitnessThreshold": 0.001,
  "maxIterations": 2000000,
  "reheatFactor": 0.2
}

Exploration-Focused Setup (Escape local optima):

{
  "initialTemp": 5000.0,
  "coolingRate": 0.999,
  "reheatFactor": 0.8,
  "windowSize": 10000
}

Output Files

Primary Outputs

1. Synthetic Population CSV (output parameter)
   • Maps geographical areas to synthetic individual IDs
   • Format: area_id,microdata_id
2. Fraction Comparisons CSV (validate parameter)
   • Shows how well constraints are matched
   • Format: geography_code,variable,synth_fraction,constraint_fraction

Execution Results

The tool returns a JSON object with:

{
  "status": "ok" | "error",
  "message": "Description of result",
  "log": ["Line 1", "Line 2", ...]
}

Validation and Visualization

A Jupyter notebook called CheckResults.ipynb is included to visualize COMPASS's performance. It plots the predicted fractional values for each grouped variable alongside the corresponding synthetic fractions.

Requirements:

• Groups file (e.g., data/BlockWorld/artificial_groups.csv)
• Results file (e.g., results/artificial_synthPopSurvey.csv)

Complete Example Configuration

{
  "constraints": "data/BlockLand/artifical_cencus.csv",
  "microdata": "data/BlockLand/artifical_hh_survay.csv",
  "groups": "data/BlockLand/artificial_groups.csv",
  "output": "results/artificial_synthetic_population.csv",
  "validate": "results/artificial_synthPopSurvey.csv",
  "initialTemp": 1000.0,
  "minTemp": 0.001,
  "coolingRate": 0.997,
  "reheatFactor": 0.3,
  "fitnessThreshold": 0.01,
  "minImprovement": 0.001,
  "maxIterations": 500000,
  "windowSize": 5000,
  "change": 100000,
  "distance": "NORM_EUCLIDEAN",
  "useRandomSeed": "no",
  "randomSeed": 42
}

Troubleshooting

Common Issues

Log Messages

Performance Tips

1. Start with smaller data: Test with a subset of constraints/microdata
2. Increase fitness threshold: Higher threshold = faster convergence
3. Reduce max iterations: Lower for testing, higher for production
4. Use appropriate distance metric: NORM_EUCLIDEAN is good for mixed scales
5. Enable deterministic mode: Set useRandomSeed: "yes" for reproducible testing

How It Works (Detailed)

1. Input Validation

All inputs are validated once at startup:

• Constraint values must match microdata dimensions
• Zero constraints enforced (if constraint is 0, microdata must be 0)
• Weights length must match constraint length

2. Population Initialization

For each area:

• Calculate population size (rounded from constraint.Total)
• Identify valid microdata records (satisfy zero constraints)
• Randomly select N records with replacement
• Compute initial aggregate totals

3. Simulated Annealing Optimization

For each iteration:

1. Propose Change: Randomly select:
   • A position in the population to replace
   • A valid microdata record to insert
2. Evaluate: Compute new aggregate totals and fitness
3. Metropolis Criterion:
   • If improvement (delta < 0): Accept
   • If equal (delta == 0): Accept (explore flat terrain)
   • If worse (delta > 0): Accept with probability e^(-delta/temp)
4. Temperature Schedule:
   • Cool: temp *= coolingRate
   • Reheat: temp *= (1 + reheatFactor) if stagnation detected
5. Stagnation Detection:
   • Monitor relative improvement over rolling window
   • Reheat if improvement falls below threshold
   • Exit if complete stagnation

4. Convergence Criteria

The algorithm stops when any of these are true:

• Best fitness ≤ fitnessThreshold
• maxIterations reached
• temperature ≤ minTemp
• changes ≤ 0 (all moves rejected)
• complete stagnation detected

5. Deterministic Mode

When useRandomSeed: "yes":

• Each area gets a deterministic RNG seeded by hash(areaID) + randomSeed
• Results are reproducible across runs regardless of worker scheduling
• Uses FNV-1a hash for stable area ID hashing

Development Status

Version: 0.80 (Experimental)

Acknowledgments

This project was developed with contributions from:

• Core Algorithm Development: Alison Heppenstall, Ricardo Colasanti, Hugh Rice, Andreas Hoehn
• Initial Project Design: Nik Lomax, Alison Heppenstall
• Documentation and Code Comments: Comprehensive documentation, code commenting, and technical writing assistance provided by AI Assistant through DeepSeek AI based on the initial README and code comments by Ricardo Colasanti

The simulated annealing implementation, distance metrics, parallel processing architecture, and cross-platform build scripts were documented and commented with the assistance of AI to ensure clarity, maintainability, and usability for researchers and developers.

Thank you to Stephen Clark of School of Geography at the University of Leeds for invaluable feedback.

License

This code is part of the COMPASS project. See the main project license for terms of use.

Documentation last updated: August 2026
Tool under active development - Parameters and features may change
